Outdoor Kitchen Plan, 066X-0005
All images are copyrighted by our designers. Photos may reflect modifications made by the builder/homeowner.
Rustic dining pavilion with outdoor kitchen features timber and stone blending nicely with Craftsman style homes
Ideal for sharing food and drink with friends and family outdoors all summer long
Features stylish vaulted ceiling
Kitchen offers 24" and 36" base/lower cabinets on both sides, two 36" upper cabinets on both sides, an adjustable metal grill with ash pan, and a cast concrete counter top and back splash.
Per designer, roof system can be stick/conventionally framed or trussed based on local building codes and common practices/standards.
| Unheated Square Feet | |
| Other | 475 |
| Width | 19 ft. 0 in. |
| Depth | 26 ft. 7 in. |
| Approximate Height | 17 ft. 1 in. |
| Ceiling Height | |
| First Floor | 9 ft. 0 in. |
| Roof Pitch | 6/12 Main |
| Roof Framing |
|
| Foundation Options |
|
| Exterior Wall Options |
|
Rustic dining pavilion with outdoor kitchen features timber and stone blending nicely with Craftsman style homes
Ideal for sharing food and drink with friends and family outdoors all summer long
Features stylish vaulted ceiling
Kitchen offers 24" and 36" base/lower cabinets on both sides, two 36" upper cabinets on both sides, an adjustable metal grill with ash pan, and a cast concrete counter top and back splash.
Per designer, roof system can be stick/conventionally framed or trussed based on local building codes and common practices/standards.
Purchased as PDF or CAD file
PDF and CAD files are delivered by email, and have no shipping and handling cost.
Purchased as paper plans
* Scroll right to view table
| Continental US | Canada | AK/HI | *International | |
|---|---|---|---|---|
| Regular 8 - 12 business days | n/a | n/a | n/a | n/a |
| Priority 3 - 4 business days | n/a | n/a | n/a | n/a |
| Express 1 - 2 business days | n/a | n/a | n/a | n/a |
